Are You Looking for a High-Performance PCB? Try the Rogers RO4003C
Are You Looking for a High-Performance PCB? Try the Rogers RO4003C
Are you tired of subpar circuit boards that fail to meet your high standards? Look no further than our newly shipped PCB, designed with precision and built to perform.
We are proud to introduce our latest product,whichdesigned with precision and built to perform. This PCB is made with high-quality Rogers RO4003C material, featuring a lead-free process and a wide -40℃to +85℃operation range. The stack-up includes a base copper of 17um, a dielectric of 20mil, and another base copper of 17um, ensuring excellent electrical performance.
The construction details of this PCB are impressive, with a board dimension of 70.00 x 50.00 mm=2Types=2PCS, +/- 0.15mm, and a minimum trace/space of 5/7 mils. The minimum hole size is 15 mils, with no blind or buried vias. The finished board thickness is 0.58mm, and the panelization details are as per Greber.
This PCB also features a finished Cu weight of 1 oz (1.4 mils) all layers, a via plating thickness of 1 mil, and a surface finish of lead-free HASL. While the top silkscreen and bottom silkscreen are not available, the top solder mask is green, and the bottom solder mask is not present. To ensure the highest quality, this PCB has undergone a 100% electrical test.
While impedance matching is not included in the design, the panelized solder paste stencil is supplied for the top side, making it easier for the user to assemble components. The PCB statistics are impressive, with 66 components, 97 total pads, 51 thru-hole pads, 19 top SMT pads, 27 bottom SMT pads, 84 vias, and 5 nets.
If you have any technical questions, please reach out to Jane at sales@bichengpcb.com. Trust our newly shipped PCB to deliver superior performance and reliability for all your electronic needs.
What is Rogers RO4003C PCB?
The Rogers RO4003C PCB is a highly advanced and superior quality circuit board that offers exceptional electrical performance, thermal stability, and dimensional stability. This PCB is made with top-of-the-line 20mil Rogers RO4003C material, which offers a wide range of features and benefits that make it an ideal choice for high-frequency applications. In this article, we will take a closer look at the key features and benefits of the Rogers RO4003C PCB.
Dielectric Constant and Dissipation Factor of Rogers RO4003C PCB
The Rogers RO4003C PCB is an innovative and advanced circuit board that is made with high-quality materials. Its dielectric constant and dissipation factor are impressive, with a typical value of 3.38±0.05 at 10 GHz/23℃. This makes it ideal for high-frequency applications that require low loss and low dispersion. The thermal coefficient ofεis also noteworthy, with a value of +40 ppm/℃at -50℃to 150℃.
Thermal Properties of Rogers RO4003C PCB
The Rogers RO4003C PCB offers unmatched thermal stability. It can operate in a wide temperature range of -40℃to +85℃, making it ideal for applications that require reliable performance in harsh environments. Furthermore, its thermal conductivity of 0.71 W/M/K at 80℃ensures excellent heat dissipation.
When it comes to dimensional stability, the Rogers RO4003C PCB is equally impressive. Its coefficient of thermal expansion is 11 ppm/℃, and its Tg is >280℃TMA A. This ensures that the PCB can maintain its shape and size even under extreme temperature changes, ensuring reliable performance.
Electrical Strength and Volume Resistivity of Rogers RO4003C PCB
The Rogers RO4003C PCB also offers exceptional electrical performance, with an electrical strength of 31.2 (780) Kv/mm (v/mil) at 0.51mm (0.020"). This makes it ideal for high-voltage applications. Additionally, its volume resistivity of 1.7 x 1010 MΩ.cm COND A ensures excellent insulation properties.
Mechanical properties for Rogers RO4003C PCB
In terms ofmechanical properties, the Rogers RO4003C PCB is also impressive. It has a tensile modulus of 19,650 (2,850) MPa (ksi) RT, a tensile strength of 139 (20.2) MPa (ksi) RT, and a flexural strength of 276 (40) MPa (kpsi). This means that the PCB can withstand mechanical stress and strain without compromising its performance.
Lead-Free Process Compatibility of Rogers RO4003C PCB
The Rogers RO4003C PCB is also lead-free process compatible, making it an ideal choice for environmentally conscious manufacturers who want to reduce their carbon footprint. Moreover, it is cost-effective to manufacture, making it an excellent option for a wide range of applications.
Conclusion
In summary, the Rogers RO4003C PCB is a highly advanced and superior quality circuit board that offers excellent electrical performance, thermal stability, and dimensional stability. Its impressive features make it an ideal choice for high-frequency applications, while its lead-free process compatibility and cost-effectiveness make it an excellent option for environmentally conscious manufacturers. Whether you are building a prototype or a production run, the Rogers RO4003C PCB is an excellent choice for all your electronic needs.
